Details
- An ultra-wide, high performance alloy rim, weight optimized for Enduro, Trail and All Mountain use
- Tubeless ready with anti-burp rim hooks to prevent the loss of pressure and keep tires firmly in place
- 32 holes with an inner width of 35mm and outer width of 39.5mm provides ultra-wide support for Plus-Size and high-volume tires
- The corrugated rim center adds exceptional strength, making it more rigid and allowing the rim to be wider without adding material
- Shotpeen finish to increase fatigue life and make it more durable
Specs
| Rim | Alloy |
|---|---|
| Brake Compatibility | 6-bolt |
| Cassette Compatibility | Select from dropdown |
| Hub | SPANK HEX J-TYPE |
| Spokes | J-Hook, triple butted 2.2/1.8/2.0 |
| Spoke Count | 32 |
| Nipples | Alloy DSN |
| Lacing | 3 cross lacing |
| Inner Rim Width | 35 |
| Outer Rim Width | 39.5 |
| Rim Depth | 22 |
| Valve Type | Presta |
| Extras | Tubeless taped & valved |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| 148 x 12mm / Shimano HG / Black/Silver / 29-inch | 04710155965043 | C090732RESJ620A | 210000058507 |
| 148 x 12mm / Shimano Micro Spline / Black/Silver / 29-inch | 04710155969447 | C090732RE3J620A | |
| 148 x 12mm / SRAM XD / Black/Silver / 29-inch | 04710155965050 | C090732REXJ620A |
