Details
The City Bike Line is a thoughtfully designed, modern take on a classic style. Commuter-minded features such as fenders and a chain guard not only keep you and your bike clean but also contribute to a classic, refined design that includes a riveted leatherette saddle and retro-inspired metal pedals. Providing comfort without sacrificing style, the mustache-style handlebars outfitted with lock-on leatherette grips keep you in an upright riding position as you coast through the city streets on cushy 35c tires, while a coaster brake provides worry-free stopping power.
| 48cm | 53cm | 58cm | |
|---|---|---|---|
| A. Reach | 382mm | 389mm | 401mm |
| B. Stack | 533mm | 543mm | 552mm |
| C. Standover | 761mm | 789mm | 816mm |
| D. Effective Top Tube | 545mm | 555cm | 570mm |
| E. Head Tube Angle | 70° | 70° | 70° |
| F. Head Tube Length | 130mm | 130mm | 140mm |
| G. Seat Tube Angle | 73° | 73° | 73° |
| H. Seat Tube Length | 480mm | 530mm | 580mm |
| I. Bottom Bracket Height | 285mm | 285mm | 285mm |
| J. Bottom Bracket Drop | 60mm | 60mm | 60mm |
| K. Fork Rake/Offset | 60mm | 60mm | 60mm |
| M. Wheelbase | 1062mm | 1073mm | 1088mm |
| O. Chainstay Length | 448mm | 448mm | 448mm |
Specs
| Frame | Hi Tensile Steel |
|---|---|
| Fork | Hi Tensile Steel, Lugged |
| Wheels | 700c Wheel Set |
| Hubs | 3 Speed Internal, Spacing: F: 100mm / R: 120mm |
| Tires | 700c x 35, Suggested Max Tire: 35mm |
| Brakes | Kick-back Coaster Brake |
| Handlebars | Moustache Handlebars, Width: 560mm |
| Stem | 1" Threaded Quill Stem, Clamp Diameter: 25.4mm, Length: 90mm, Rise: -17° |
| Headset | 1" Threaded |
| Seatpost | Steel, Diameter: 25.4mm |
| Saddle | Leatherette Retro Style |
| Pedals | Retro Style Metal Pedals |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Flat Black / 48cm | 796201613247 | 50-ELST-048-003 | 210000055064 |
| Flat Black / 53cm | 796201613254 | 50-ELST-053-003 | 210000055065 |
| Flat Black / 58cm | 796201613261 | 50-ELST-058-003 | 210000055066 |
